Our Fleet » SUPERBA 9538165

SUPERBA

GSI 37K DWT

FLAG:

BAHAMAS

PORT OF REGISTRY: NASSAU
OWNERS: Skylark Seacarriers Limited
MANAGERS: SUPER-ECO TANKERS MANAGEMENT INC.
CALL SIGN: C6AR9
IMO NUMBER: 9538165
YEAR BUILT: 2014
PLACE BUILT: GUANGZHOU SHIPYARD INTERNATIONAL CO. LTD.
TYPE OF SHIP: CHEMICAL TANKER
HULL: DOUBLE HULL
PLACE BUILT: GUANGZHOU SHIPYARD INTERNATIONAL CO. LTD.
TYPE OF SHIP: CHEMICAL TANKER
HULL: DOUBLE HULL
Summer Deadweight 37949.01 MT
Gross Tonnage 25.269
Net Tonnage 10.334

L.OA. 183.17 M
L.B.P. 178.50 M
Beam 31.031 M
Depth 16.00 M
Summer Draft 10.5 M
TPC 52.7 MT

Cubic Capacity Incl. Slops 98% 44716,32
Freeboard (S. DRAFT) 5.515
Freeboard (SBT): 9.197
Parallel Body Length (Light Condition) 57.7
Keel To Mast 42.23
Crane SWL 1 X 10T
Tanks Coated YES
Coating PHENOLIC EPOXY COATING
Type of Cargo Heating System HEATING COILS
Crude Oil Washing YES
Inert Gas System YES
Segregated Ballast Tanks YES
No of Manifolds 6 x 14”
Type Of Manifolds CAST STEEL BUTTERFLY
Distance Rail To Manifolds 4,600 Millimetres
Distance Bow To Manifolds 92.68 Metres
Distance Deck To Center Of Manifolds 2.1 mtrs
Manifold Height of sea level upon completion of discharging 11.27 mtrs













11 x 406/355mm (16/14")
4 x 406/305mm (14/12")
4 x 355/305mm (10/10")
4 x 355/355mm (14/8")
2 x 355/254mm (16/10")
NUMBER OF CARGO OIL TANKS 6 WING CARGO
  OIL TANKS & 2 SLOP TANKS

NUMBER OF SEGREGATIONS 6

CARGO PUMPS 10 CENTRIFUGAL DW 500m3/HR
  2 CENTRIFUGAL DW 300m3/HR
   CENTRIFUGAL DW: 100m3/HR
CAPACITY OF CARGO PUMPS 3000 Cu. Metres/Hour

MAIN ENGINE DMD MAN B8W 5S50MZ-BMK 9.2 Tier II

B.H.P.: 9250

  CAPACITY CAPACITY  100% m3 98% m3
No 1 CARGO TANK (P) 2937.5 2878.8
No 1 CARGO TANK (S) 2924.6 2866.2
No 2 CARGO TANK (P) 4173.5 4090.1
No 2 CARGO TANK (S) 4173.5 4090.1
No 3 CARGO TANK (P) 4279.4 4193.9
No 3 CARGO TANK (S) 4279.4 4193.9
No 4 CARGO TANK (P) 4279.7 4194.2
No 4 CARGO TANK (S) 4279.7 4194.2
No 5 CARGO TANK (P) 4242.3 4157.5
No 5 CARGO TANK (S) 4242.3 4157.5
SLOP TANK (P) 3373.9 3306.5
SLOP TANK (S) 3373.9 3305.9
GRAND TOTAL 46559.7 45628.8
  TANKS
100,00%
CAPACITY
m3
GROUP 1 1P&1S 5862.1
GROUP 2 2P&2S 8347.0
GROUP 3 3P&3S 8558.8
GROUP 4 4P&4S 8559.4
GROUP 5 5P&5S 8484.6
GROUP 6 SLOP P&S 6747.8

TOTAL CAPACITY BALLAST (m3)   17710.5
TOTAL CAPACITY FUEL OIL (m3)   1174.4
TOTAL CAPACITY DIESEL OIL (m3)   175.8
TOTAL CAPACITY FRESH WATER   398.1
